Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D)

A walking firefighting platform from Unitree that carries a water and foam cannon into stairwells, tunnels and smoke-filled buildings a crew should not enter first, with laser SLAM navigation to find its way. Robots Europa supplies it to fire services and industrial safety teams across the EU and the DACH region.

In stock

BRAND:
UNITREE ROBOTICS
MODEL:
B2-XF2-D
PART #:
B2-XF2-D
ORIGIN:
China
AVAILABILITY:
SUBJECT TO AVAILABILITY
SKU:
Unitree-B2-XF2-D
Free Shipping

Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D)

Every fire crew knows the arithmetic of distance: the closer a firefighter must stand to reach the seat of a fire, the more the operation depends on luck. A monitor bolted to an engine keeps people back, but it stays wherever the engine can park. The Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D) breaks that link. It puts a water and foam cannon on four legs and sends it up steps, across rubble and into smoke, while the crew directs the attack from a position they would choose freely. This configuration adds Laser SLAM navigation, so the robot can build its own picture of the ground it crosses.

Robots Europa, based in Dublin, sells and supplies this configuration to fire services, industrial safety teams and public-sector buyers across the European Union and the DACH region. Robots Europa prepares each quotation against the exact configuration requested, arranges delivery to the operating site, and remains the point of contact for support once the robot is in service.

Background

Unitree Robotics and the B2 line

Unitree Robotics is a Chinese manufacturer that made its name with legged robots, moving from compact research quadrupeds to industrial-grade platforms built for inspection, security and emergency work. The B2 is its heavy-duty quadruped: a larger, more robust frame intended for outdoor deployment and for carrying equipment rather than merely demonstrating locomotion. The fire rescue versions take that platform and specify it for firefighting, adding a water cannon and the protection a wet, hot environment demands. Further configurations of the same base are collected in the Unitree B2 category.

Why the XF2 designation matters

The manufacturer's naming carries a practical distinction. Models designated XF2 or F2D include the Laser SLAM kit for autonomous navigation, while models designated XF1 or F2 are delivered without SLAM navigation. As an XF2 model, the B2-XF2-D belongs to the navigating group. Combined with a 3D LiDAR, two depth cameras and two optical cameras on the base robot, this gives the platform the means to map its route rather than rely solely on an operator watching a video feed through smoke.

Technical Specifications

SpecificationValue
Dimensions (standing)Approx. 1098 mm × 450 mm × 645 mm
Dimensions (lying)Approx. 880 mm × 460 mm × 330 mm
Total weightApprox. 75 kg (including battery)
Battery45 Ah (2250 Wh), voltage 58 V
Running speed6 m/s
Payload (while walking)≥ 40 kg
Protection ratingIP67
Operating temperature-20°C to 55°C
Climbing angle45°
Maximum step height (facing front)40cm
Maximum jump distance1.6 m
Sensors3D-LiDAR × 1 + Depth camera × 2 + Optical camera × 2
Interfaces1000M-Base-Ethernet × 4, USB 3.0 × 4, 12V × 4, 5V × 1, 24V × 4, BAT × 1
NavigationLaser SLAM kit (XF2 and F2D models)
Water cannon pitching range5 - 85° (with body-compensated angle)
Water cannon flow rate40L/s
Water cannon mediaWater and foam
Water cannon firing range60m

Specifications as published by the manufacturer; confirmed against the datasheet at quotation.

The manufacturer has not published the weight of the water cannon, the Wi-Fi specification or the software and SDK support for this version; these are confirmed at quotation.

What does the XF2 designation add over XF1 and F2 models?

The difference is navigation. A quadruped without SLAM depends on an operator to steer every metre, which is workable in open yards but tiring and error-prone in corridors filled with smoke, where camera images lose contrast and orientation becomes difficult. With the Laser SLAM kit, the B2-XF2-D can build a map of its surroundings from its LiDAR data and navigate against it. For a fire service, that means a robot that can be guided to a waypoint rather than driven step by step, freeing the operator to concentrate on the cannon and on what the cameras reveal.

The XF1 and F2 models are delivered without SLAM navigation. They may suit organisations that intend to operate purely by remote control or that plan to integrate their own navigation stack. Buyers who expect to work in unfamiliar buildings, tunnels or plant areas will generally find the navigating configuration the more useful starting point, and Robots Europa can set out the differences between the variants on request.

How does a walking water cannon change the fireground?

Wheeled and tracked firefighting robots are effective on flat, open ground. Legs open another category of terrain. The B2 base robot handles steps of up to 40cm facing front, and the source highlights its stability and balance when climbing fire stairs. It manages a climbing angle of 45° and a jump distance of 1.6 m, so debris, kerbs and uneven floors become obstacles to cross rather than reasons to turn back.

Once in position, the cannon does the work. Its pitching range of 5 - 85° is compensated for the body's angle, which matters on a platform that stands on slopes and stairs. A flow rate of 40L/s and a firing range of 60m allow a substantial attack from a distance, and because it handles both water and foam, the same robot can serve at structural fires and at fuel or chemical incidents. The IP67 protection rating and an operating range of -20°C to 55°C reflect the conditions it is designed for, and the battery can be replaced quickly while water-tightness is maintained, which shortens the pause between deployments. The source also states that joint performance has increased by 170%.

Who is the Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D) for?

Municipal and regional fire and rescue services are the most obvious buyers, particularly those responsible for multi-storey buildings, underground car parks or transport tunnels, where access by vehicle is limited and the risk to crews is high. The combination of stair capability and navigation addresses exactly those settings.

Industrial fire brigades at refineries, chemical plants, logistics hubs and energy sites form a second group. Foam capability and the ability to approach a hazard while staff stay back fit the incident profiles these teams train for. Airport and port emergency services may evaluate it on similar grounds.

Research institutes, training academies and civil-protection agencies testing robotic support for emergency response are a third segment. The interfaces on the base robot, including four Gigabit Ethernet ports, four USB 3.0 ports and several power outputs, give integrators room to add equipment. Organisations that need only remote-controlled operation may consider the XF1 or F2 models without SLAM instead; other B2 configurations are listed in the Unitree B2 category.

What is the Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D) used for?

  1. Interior fire attack: carrying the water cannon into burning structures so crews can apply water from a protected position.
  2. Fuel and chemical incidents: applying foam where approaching on foot would expose firefighters to toxic or explosive conditions.
  3. Stairwell and multi-level access: climbing fire stairs to reach upper or lower floors that vehicles cannot.
  4. Tunnel and underground operations: navigating long, smoke-filled passages with Laser SLAM support.
  5. Situational reconnaissance: relaying LiDAR, depth and optical camera information to incident command before crews commit.
  6. Industrial site protection: standing by at high-risk plants as a deployable asset for the on-site fire brigade.

Pricing and Availability

Robots Europa supplies the Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D) by quotation, so that the configuration, scope of delivery and any optional payloads match the operational requirement. Delivery, customs and support are arranged with the quotation. Payloads shown in manufacturer material, such as the optional 3D laser mobile scanning system, are not included in the standard scope and are quoted separately where required. A request for a tailored quotation is available on this page.

Frequently Asked Questions

Does the B2-XF2-D include SLAM navigation?

Yes. Models designated XF2 or F2D include the Laser SLAM kit for autonomous navigation, and the B2-XF2-D is an XF2 model.

Can the robot climb stairs?

Yes. It ascends and descends steps of up to 40cm facing front and is described as having excellent stability and balance on fire stairs.

What can the water cannon deliver?

The cannon handles both water and foam, with a flow rate of 40L/s, a firing range of 60m and a pitching range of 5 - 85° with body-compensated angle.

Is the robot protected against water?

The B2 base robot carries an IP67 protection rating, and its battery can be replaced quickly while water-tightness is maintained.

How much can it carry?

The B2 base robot carries a payload of at least 40 kg while walking.

What is included in the delivery?

The delivery comprises the robot dog, a B2 battery (45 Ah / 2250 Wh), a charger, a remote control, an air transport box and, depending on the model, a tool kit. Robots Europa confirms the exact scope on the quotation; payloads shown in manufacturer material are not included.

Where can I buy the Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D) and what does it cost?

Robots Europa supplies it across the EU and the DACH region by quotation. The cost depends on the configuration, optional payloads and delivery requirements, so a tailored quotation can be requested on this page.

Summary

Firefighting has always been a negotiation with distance, and the Unitree B2 Fire Rescue Quadruped Robot Dog (B2-XF2-D) shifts it in the crew's favour. It brings a water and foam cannon up stairs and over obstacles that stop wheeled machines, it protects its electronics to IP67, and as an XF2 model it navigates with Laser SLAM rather than relying on an operator for every step. For fire services, industrial brigades and research teams in Europe that want the hazard approached by a machine rather than a person, supplied and supported by Robots Europa, this page is the starting point.

Specifications

General

BRAND UNITREE ROBOTICS
MODEL B2-XF2-D
PART # B2-XF2-D
ROBOT TYPE QUADRUPED
ROBOT USE FIREFIGHTING
FCC APPROVED Yes
FCC ID 2A5PE-YUSHU006

What's included

Unitree B2-Xf2-D (B2-XF2-D)
